Product Details
Features
- DIRECT DRIVE DRUM: No chains or chain cases to break, wear or lubricate
- ULTRA SHORT DRIVE MOTOR: Shortest in class, sits within the side wing
- INTERNAL LUBRICATED DRUM SUPPORT BEARINGS: Never require lubricating
- SEALED INTERNAL DRUM: Protects bearings and drive from damage
- SEALED, SHIELDED & LIFETIME LUBRICATED QUADROD LINKAGES: Never require greasing
- SEALED HARDILUBE BUSHES THROUGHOUT: Never require greasing
- RETRACTING FRONT BLADE: Retracts to allow rake to function normally
- PIVOTING REAR BLADE INDEPENDENT FROM RAKE: Grades forward & reverse on grade
- CHAMFERED CARBIDE TEETH: Reduces compaction, increases penetration & fracturing
- ONE TOUCH STONE BARRIER: Open or close stone barrier in seconds
- OPERATES FORWARDS & REVERSE FROM SCREEN: No need to reverse hydraulic flow
- BLADE HEIGHT INDEPENDENT OF RAKE: Precision grade at any height Forwards & Reverse
- 8 DEGREES OF BLADE TILT IN BOTH DIRECTIONS: Rake & Grade independent of base machine
- WIDE RANGE OF HITCH PLATES: Adapts to most Mini Skids
- WIRELESS CONTROL SCREEN: No cables anywhere on boom to get damaged
- QUADGRADE 2D CONTROL SYSTEM: Proven system, operates with Laser, Slope & Sonic sensors
- +/- 5” (120mm) Increment / Decrement from the screen: Set perfect grade on the fly
- HIGH-CAPACITY HYDRAULIC VALVES: Accepts up to 29GPM (110l/min)
- TWIN PARABOLIC MIRRORS WITH PROTECTION BAR: See both the blade and the side wings
- MOST VERSATILE ATTACHMENT ON THE MARKET: Increase your value proposition to customers
Benefits
- Increase productivity as your Power Rake can now blade in both directions
- Increase accuracy as you can Precision Power Rake & grade with the same machine
- Carry material more efficiently on grade in either direction
- Guarantee precision raking or grading accuracy with proven technology
- Tackle difficult jobs with ease due to the versatility of the PB52
Our SharpGrade Skid Steer Grader Blade attachments can be supplied in one to two weeks of order, if in stock.
Delivery will incur a freight fee if delivered out of town by truck or courier.
Spare components not sold with the attachment or out of warranty will incur a freight fee.
Warranty Inclusions:
SharpGrade Inc. (“SharpGrade”) warrants all structural products to be free from defects in material and workmanship for 12 months from date of purchase.
SharpGrade warrants all QuadRod linkages for a period of 2 years from date of purchase.
If a product manufactured by SharpGrade is proven to be defective in material and/or workmanship, any product repaired or replaced under the terms of this warranty policy shall retain the warranty period pertaining to the product’s original date of issue.
Warranty Exclusions:
This policy does not cover:
- Carrier machine, or any parts, hitches, connections, hydraulic components, tracks, electrics, electronics associated with the carrier machine.
- Accessories that are warranted directly to the Customer by third-party manufacturers.
- Product failure as a result of incorrect installation, negligence, or misuse.
- Costs associated with the removal or reinstallation of the product or machine downtime.
- Freight costs for supply of replacement parts.
- Personal injury or property damage caused by product failure, persons, place, or machine.
- General product wear and tear on ground engaging parts, tires, pins, bushings, or hitch connections.
